Food Packing (MAP)

Equilibrium Modified Atmosphere Packaging and Other Food Packaging Applications


More and more food packaging companies are utilizing Modified Atmosphere Packaging (MAP) or Equilibrium Modified Atmosphere Packaging (EMAP) to preserve the shelf life and/or appearance of their packed food.  At Environics, we know it is essential that your MAP/EMAP gases be consistent and accurate in order to guarantee the desired quality in the end products.

Download Full Datasheet (pdf)

Our Series 3000 Gas Mixing and Delivery system provides for precise mixing of MAP gases for your case ready meat packaging. Whether you are reducing the oxygen levels with nitrogen, carbon dioxide, carbon monoxide or a variety of gases, the high accuracy and consistency of our mixers makes them the units of choice for all of your needs.


Flexibility:  Environics’ systems automatically blend and dilute gases to generate precise gas mixes.  The Environics® Series 3000 Gas Delivery/Blending system offers on-site gas blending of 100% pure bulk gases and is configured to provide a solution to using costly premixed cylinders of gas.

Although two and three gas mixtures are most common, gas mixtures of more constituents can be produced. The primary benefits of the system are cost savings in using pure gases versus premixed cylinders as well as the accuracy and repeatability of the mixture.

Whether you use a variety of different gas blends or a single blend, the component concentration can be independently varied in response to your commands.  Customization of our case ready meat packaging systems is always possible.

Accuracy: Our gas mixing technology is based on very precise control of thermal mass flow controllers (EFC202). Normally, thermal mass flow controllers offer an accuracy +/- 1% of full-scale flow. However, when combined with Environics computerization and calibration, this accuracy specification is improved to +/- 1% of setpoint. The Full-scale error vs. Setpoint error document shows the 10x improvement in accuracy of a thermal mass flow controller when using Environics controlling technology.

Consistency:  Our systems have a repeatability of +/-0.05% of full scale.

Both accuracy and consistency are dependent on total flow rate.

Price Savings:  By using pure gases in place of expensive pre-mixed blends, your system will help pay for itself.

Gas Conservation:  The Series 3000 provides a controllable positive pressure to meet the requirements of a process downstream. The mixer can be configured to provide gas to a ballast tank, turning off and on as the pressure rises and falls in the tank. This is useful for gas conservation, when the demand for gas is sporadic or intermittent in use.


Optional Alarms:  An optional visual and/or audible alarm can be installed onto the top of the instrument to alert the operator of specific fault conditions. An example of a visual alarm is seen in the above picture of a custom system.  We encourage you to consider adding these alarms for all systems, and specifically when using carbon monoxide.  A condition that would trigger an alarm is if the interpreted concentration from the optional flow meters falls outside a user adjustable tolerance.

NEW FEATURE! These alarms can also be emailed to keep you updated even when you are not onsite. This requires the IP address of the email sever have a static IP address. Contact Us for more information on this exciting new feature!

Custom Systems: We have thousands of systems in the field and have developed an extensive library of applications and solutions to meet our customers' needs.  Optional features, including remote operation, alarms or a gas humidifier are available.  Contact us for more information.
